Product Description
- High volume fan provides cool air motor and pump
- Vapor discharge/oil fill port, easily removable, contains internal check valve to prevent escape of liquid oil
- Internal check valve to prevent oil back flow
- Cooling fins to keep temperature cooler during extended motor operation
- Thermally protected motor with on/off rocker switch
- Large, lightweight reinforced base for stable positioning
- Easily accessible oil drain valve
- Large oil level sight glass with max/min oil level indicator
SPECIFICATIONS:
- No. of Stages: 1
- Free Air Displacement: 6 CFM
- Ultimate Vacuum: 80 Microns
- Pump Motor: 1/3 HP
- Pump Speed: 1720 RPM
- Electrical Specs: 110/120 V/60 Hz
- Dimensions: 15 x 6.5 x 11°'àö√ë'àö'àÇ®√´°'àö¢'ÄöÄ¢
- Shipping Weight: 20.5 lbs
* PLEASE NOTE: The micron readings on all vacuum pumps represent optimal laboratory conditions. Field conditions may vary from these readings.
SERVICE INFORMATION:
Oil Capacity: 18 oz / 536 ml
